Advantages

1. 86 type panel with framed, battery free for life, generates electricity when pressed, green and environmentally friendly
2.High gloss craftsmanship, simple and beautiful, with 1 gang and 2 gang for free selection
3. Wifi(2.4G)+RF433 signal communication, remote control does not require network
4. Carefully designed, years of research and development, long distance, responsive
5. No wiring required, easy to install, saves labor and materials
6. The receiver need to connect neutral wire and live wire, compatible with AC 100~240V 50/60Hz, no flicker, stable and reliable
7. The receiver comes with overload protection and is made of PC flame-retardant material for greater safety
8. The receiver is designed with a small size and can be placed in the bottom box of the switch. It can also be inserted into the lamp tube to meet various fixing methods
9. Rocketed panel, like traditional switches, is more in line with usage habits
10. 86 standard size, reserved with screw holes, flexible and diverse installation options
11. After 200000 press tests, we provide original factory warranty services
12.Widely used: This product can be used in esidence, hotel, villa, hospital construction sites, gardens, homes, farms, factories, offices, laboratories, supermarkets. Any device can be remotely controlled through a remote control, such as light,rolling shutters, fences, fans, desk lamps

Technical parameters

1.Operating voltage: receiver AC 100-240V 50/60Hz,transmitter Kinetic power generation
2.Wireless distance: about 100 meters (open space) ，about 50 meters (no partition) (this data is the obstacle free test distance of the experimental open space, theactual distance will vary depending on the use environment and the obstacles, please take the actual distance as the standard)
3.Receiver size:49x49x23mm Transmitter size:86x86x16.5mm
4.Rated Current:AC 10A
5.Standby power:<0.25W
6.Working frequency: RF433MHZ
7.Storage switch quantity:Can store 10 wireless switch panel(can be made)
8.Wiring method：

wireless light switch receiver needs to be connected to a live wire and a neutral wire.

The (Lin) marked on the receiver is connected to the power live wire (incoming live wire), and the (Nin) is connected to the power neutral wire (incoming neutral wire).

(Lout) connects the live wire of the device that needs to be controlled (outgoing live wire), and (Nout) connects the neutral wire of the device that needs to be controlled (outgoing neutral wire).

9.S1 and S2 are reserved interfaces for connecting traditional single fire wall switches, which can form a dual control mode with wireless switches without affecting each other. If not necessary, they do not need to be connected

Package:
1 x Wireless Switches
1 x Receiver
1 x English Instructions
3 x Adhesive Rubbers

Note:

1. Our product needs to be used with a receiver, unless you have previously purchased our product and need to purchase additional accessories, otherwise purchasing a transmitter or receiver separately will not work.
2. Our product uses RF433 communication, but it cannot be mixed with other RF433 products because in addition to frequency, it also needs to meet the requirements of decoding and coding speed.
3.Wireless control does not require a power supply and can be used outdoors or in humid environments. Pressing to generate electricity does not pose a risk of electric shock
4.Cut off all power before installing the receiver.
5. Cannot be installed inside a metal box as metal will shield signals and cannot be used.
